Creator of Composite Diamond Coating®

Surface Technology, Inc. is the creator and technical leader of CDC - Composite Diamond Coating®, an exceptionally engineered coating of electroless nickel with fine diamond. The synergy of these materials makes CDC an exceptionally hard and wear resistant coating. CDC conforms to even the most complex geometries and is an excellent replacement for chrome plating. STI makes CDC available via coating services from its production facility as well as chemical products sold directly, through a network of distributors, and by agreement with licensees worldwide.

Contact STI for One-Plate® Electroless Nickel solutions, the simplest EN in the world. These One-Plate® systems use just one “Q” solution for both bath make-up and replenishment. This innovation by STI overcomes the many shortcomings of using three A, B, and C solutions. Available in low, medium, high phosphorous, and composite EN varieties. Naturally, all are RoHS compliant.”

Bor-Fuse ™

Bor-Fuse™ is a thermo chemical surface-hardening process in which boron atoms are diffused into a steel surface to form super hard boride layers. The process is advantageous for any tools or parts where exceptional hardness is required for wear or abrasion resistance.

Bor-Fuse™ is accomplished at temperatures between 850° and 950°C in an inert or reducing atmosphere. This results in the formation of a surface layer of iron boride that has a tetragonal structure and hardness values in the range of VHN100= 2000.

Bor-Fuse™ can be applied by two main methods: powder packing and paste painting. In the powder packing method, the part to be treated is embedded in a powder form of the Bor-Fuse™ chemicals. For treating specific areas, special paste forms of Bor-Fuse™ may be painted onto the specified surfaces. Even the most intricate geometries can be enhanced by this unique process.

Most construction, case-hardened, tempered, tool-making, and chemically-resistant steel types work exceptionally well in the Bor-Fuse™ process. Certain stainless steel and titanium alloys can also be treated. Following the Bor-Fuse™ process, parts may then be coated by any of Surface Technology, Inc.’s unique coatings for additional wear resistance or many other properties such as self-lubricity or light emission.
